Maseehum Task Manager Private Limited

High-Speed Scanning: Processes up to 190 cheques per minute (cpm) in standard mode and up to 160 cpm in UV scan mode, facilitating rapid transaction handling.

UV Scanning Capability: Equipped with UV sensors to capture anti-fraud patterns printed with UV ink, allowing simultaneous capture of both standard and UV images for enhanced fraud detection.

Advanced Image Processing: Supports various scanning modes, including black and white, error diffusion, fine text filtering, 256-level greyscale, and 16-level greyscale, ensuring high-quality image outputs.

Built-in 4-Line Imprinter: Allows printing of up to four lines of endorsement information on the back of cheques as they pass through the scanner, with a maximum character length of 48 characters.

Efficient Document Handling: Features an automatic document feeder (ADF) with a capacity of 250 sheets, supporting document widths from 68 to 108 mm and lengths from 120 to 245 mm.

MICR and OCR Support: Accurately reads Magnetic Ink Character Recognition (MICR) and Optical Character Recognition (OCR) data, ensuring precise data capture from cheques.

Compact and Durable Design: With dimensions of 476 x 272 x 214 mm and a weight of approximately 8.4 kg, the scanner is designed for desktop use, offering durability and ease of maintenance.

Scanning Element: CMOS Image Sensor (CMOS CIS)​

Light Source: LED / UV LED​

Scanning Side: Simplex / Duplex; front page only in UV scan mode​

Output Resolution: 100, 120, 150, 200, 240, 300 dpi; up to 200 dpi in UV scan mode​

Suggested Daily Volume: Up to 24,000 scans per day​

Connectivity: USB 2.0​

Supported Drivers: ISIS / TWAIN​Power Requirements: AC 220 - 240 V (50 / 60 Hz)​

Power Consumption: 49 W during scanning; 2.7 W in sleep mode​

Operating Environment: Temperature: 10 to 32.5°C; Humidity: 20 to 80% RH​

Consumables: Exchange Roller Kit, Ink Cartridge, Ink Disposal Tank​

Scanner Type: Desktop Sheet-Fed Scanner

Scanning Element: CMOS CIS (Contact Image Sensor)

Light Source: RGB LED

Optical Resolution: 600 dpi

Scanning Sides: Simplex / Duplex

Interface: USB 2.0 (USB 3.0 compatible)​

Black & White / Grayscale:

• 200 dpi: 25 ppm (Simplex) / 50 ipm (Duplex)

• 300 dpi: 25 ppm (Simplex) / 50 ipm (Duplex)

Color:

• 200 dpi: 25 ppm (Simplex) / 50 ipm (Duplex)

• 300 dpi: 15 ppm (Simplex) / 30 ipm (Duplex)​

Document Size:

• Width: 50.8 mm to 216 mm

• Length: 53.9 mm to 356 mm (up to 3,000 mm in Long Document Mode)

Document Thickness and Weight:

• U-Turn Path: 52 to 128 g/m² (0.06 to 0.15 mm)

• Straight Path: 40 to 209 g/m² (0.05 to 0.25 mm)

Business Card: 300 g/m² (0.35 mm) or smaller

Plastic Card: 0.76 mm or smaller; 1.4 mm or smaller for embossed cards

ADF Capacity: 30 sheets (80 g/m²)
